Designed to operate up to 32,000 factored hours between inspections, FlameSheet™ is ideally suited for shale gas, Liquefied Natural Gas (LNG), or alternate fuel operation such as ethane, propane, and hydrogen– all with a 30% Modified Wobbe Index (MWI) operational range.
FlameSheet™ Benefits:
- Up to a 30% increase in GT operating load range with single-digit NOx and CO
- Optional low-load HRSG protection setting
- Superior Fuel Flex
- 30% Modified Wobbe Index
- Ideally suited for alternate fuel operation, including hydrogen, ethane, and propane
- Up to 60% Hydrogen mix (B, E & F Class with Hyflex combustor)
- Up to 40% Ethanes (C2)
- Up to 10% Butanes (C4-C6)
- Up to 20% Propane (C3)
- NOx as low as 5ppm
- Peaking power at constant NOx emissions
- Dual fuel capable
- Up to 32K / 1250 start inspection intervals
- Compatible with the plant’s existing GT controller and fuel skids
Extended durability and improved maintenance of the combustion system and overall power plant include:
- Turndown capability mitigates daily plant cycling
- Optional low-load HRSG protection setting
- Minimized hot combustor operating components
- Modular design reduces installation time
- Wide fuel flexibility
